Bluetooth Vibration Sensors / Bluetooth Accelerometers

What is a Bluetooth Vibration Sensor?

A Bluetooth Vibration Sensor is an Accelerometer capable of recording vibration data and transfer it to a receiver using Bluetooth standard protocol. These sensors usually integrate an accelerometer and a bluetooth transmitter to establish wireless connectivity. Hence having the capability to connect via peer to peer or mesh network.

Security.

The signal from the Phantom sensors is encrypted which ensures the reliability of the information and the security of your data..

Bluetooth Vibration Sensors are used today for multiple purposes, being online Condition Monitoring the most important one. Bluetooth 5.0 mesh network technology allows to easily build big networks of sensors. Additionally, the capability of Modbus Communication is an excellent feature that allows automation to be integrated to the condition monitoring at the same time.

What is Modbus?

Bluetooth Vibration Sensor – High Range

The Bluetooth Accelerometer Phantom Expert (EPH-V11) is a wireless vibration sensor designed for permanent mounting. Phantom Expert is a fully configurable sensor using the Phantom Manager Application. Phantom Expert can record a vibration FFT from 3 axes simultaneously X, Y and Z, or each axis can be programmed independently within the Phantom Manager application for more flexibility, higher sample rates, longer recordings, recording as often as every 10 minutes and more. In addition, it includes a battery that can last to measure up to 100,000 recordings that can be changed at the end of its useful life.

RETAIL PRICE $279.95

Phantom ATEX – High Range Sensor

The new member of the Phantom family. Same specs (except battery) as the Phantom Expert but now with ATEX Certification (Ex ic IIC T6 Gc X & Ex ic III Dc X) for gas and dust environments!

Phantom ATEX (EPH-ATX15 & ATX16) is a Triaxial Wireless Vibration Sensor able to send 3 simultaneous FFT and Time waveform recordings at once. Also, our Wireless Vibration Sensor wake up on high vibration levels in order to send data and alarms.

As an additional value, our Wireless Vibration Sensor have a built-in integrator, as a result, it can internally calculate velocity parameters for alarms. This way, RMS values can be sent as well with a selectable periodicity.

MSRP $279.95 USD

Phantom Gen 2 – Wireless Vibration Sensor

The newest Wireless Vibration Sensor of the Phantom Family. Many of the same characteristics as the other vibration Phantom but smaller!. Phantom Gen 2 (EPH-V17 & V18) records vibration FFT from 3 axes simultaneously X, Y and Z up to 4 times per day. In addition, it includes a battery that can last to measure up to 12,000 recordings that can be changed at the end of its useful life.

Bluetooth ICP Accelerometer – Biaxial – Ultra Low Noise

Phantom EPH-V12 sensor is an ultra-low noise Biaxial (2-Axis) wireless Bluetooth Accelerometer for permanent mounting. This sensor incorporates 2 standard ICP accelerometers. Hence, this bluetooth accelerometer was designed for high speed machines. The EPH-V12 model also includes a battery that can last to measure up to 100,000 recordings and that it can be changed at the end of the of its useful life.

RETAIL PRICE $695.00

Bluetooth Vibration Sensor – High Sensitivity

Bluetooth Accelerometer Phantom EPH-V10 is a wireless vibration sensor designed for permanent mounting. Phantom records vibration FFT from 3 axes simultaneously X, Y and Z, or each axis can be independently programmed just like the EPH-V11. In addition, it includes a battery that can last to measure up to 100,000 recordings and that it can be changed at the end of the of its useful life.

RETAIL PRICE $279.95

WiSER3x

Portable Wireless Triaxial Accelerometer – WiSER 3X

The WiSER 3X is designed for route based and off-route analysis. This wireless triaxial accelerometer is fully compatible with the free WiSER Vibe and WiSER Balance Apps and Digivibe application compatibility. It is the latest generation of wireless accelerometers, capable of sending 4 vibration channels in real time for X, Y and Z axes as well as an additional reference channel for phase comparison. In addition to being ultra-portable, WiSER 3X incorporates start and stop functionality in the same power button, to save valuable time during data collection.

MSRP $2495.00 USD

Wireless_Accelerometer_Wiser

Portable Wireless Accelerometer – WiSER

WiSER is a single Axis Dual Channel wireless accelerometer and vibration analyzer compatible with the WiSER Vibe and WiSER Balance apps as well as Digivibe software. This vibration analyzer is ultra-portable, literally pocket-sized. WiSER Vibe application is able to save the data on the mobile device, as well as export it to the cloud. In fact, the data registered by WiSER Vibe can be viewed with Digivibe with 100% compatibility.

MSRP $1995.00 USD

All in One Phantom Sensor – Vibration, Current and Temperature

Meet the new member of the Phantom family. Phantom All in One (EPH-U14) take 3 types of measurement parameters with only one module: Vibration, Current and Temperature. Our Phantom condition monitoring system will help you to predict machine failures and save huge amount of costs due to non-programmed down times in production.

Bluetooth Temperature Sensor – Thermocouple

The Phantom temperature contact sensor (EPH-T25) is designed for long term exposure to your machines and surfaces. Phantom temperature sensor can record accurately from -210ºC up to 1,800ºC. As every other phantom, it includes a battery with an estimated life of 2 to 5 years and can accept up to 4 channels of thermocouple inputs.

RETAIL PRICE $179.95

Modbus is available in this sensor for Automation processes.

Bluetooth-Temperature-Sensor-non-contact

Bluetooth Temperature Sensor – Non-Contact

This Bluetooth Temperature sensor embeds an IR sensor and brings you the commodity of technology: no wires. The sensor can read temperature with a distance of 1 meter using a high-technology thermo receptor with an amazing accuracy. The battery lasts as long as any other Phantom sensor and can be easily replaced if needed.

RETAIL PRICE $179.95

Additionally Modbus is available in this sensor for Automation processes.

Bluetooth Speed Sensor – RPM

This Bluetooth Speed sensor uses a Hall Effect switch and a neodymium magnet, all included in the kit. You can easily analyze the revolutions per minute of any rotor, turbine or vent with incredible precision.

RETAIL PRICE $179.95

Modbus comunicación included for automation.

Bluetooth Current Sensor

EPH-C31 is a 3 channel Bluetooth Current Sensor (Amperage) which uses a simple installation to easily monitor the electrical current of your machines and devices. From 1 to 500 AMP our sensors can measure with precision the power consumption of your electric devices. Each sensor includes 3 simultaneous channels to measure each phase.

RETAIL PRICE $179.95

Modbus available for Automation or Scada systems.

Bluetooth General Purpose Sensor

Use it with Any Available Sensor in the Market !! – The general purpose wireless sensors are able to monitor virtually any type of signal and is compatible with other kind of sensors including: Displacement, speed, and proximity. All our General Purpose wireless sensors come with the capability to collect up to 2 channels.

RETAIL PRICE $179.95

Modbus Available

Bluetooth 4-20 mA Sensor

EPH-G61 is a 4-20 mA sensors to Bluetooth converter. EPH-G61 features an upgraded version with 24 bits and 4-20 mA input interfaces. This means that you can use any other sensor that can provide a 4-20 signal to implement your data into an integrated wireless system.

RETAIL PRICE $179.95

Modbus available.

Meet Our Products

GX400

4 Channel Interface
DigivibeMX Electronics
  • 4 Channel Wired Interface
  • 2 ICP monoaxial Accelerometers (100 mV/g)
  • Frequency range up to 15kHz
  • Up to 4 Simultaneous Channels of Data Collection
  • No Calibration of GX400 Required as NIST Traceable Accelerometers are Calibrated
  • Ideal for Real Life ODS & Route Based Data Collection
